Spiro Gear
Spiro Gear
| Ratio | 241k |
| Max. Rated Torque | 1.5~2.0 Kgf.cm |
| Max. Gear Breaked Torque | 4~5 Kgf.cm |
| Gearbox Efficiency | 45%~60% |
| Model | Ratio | Voltage (V) | No-Load | Rated | Stall | ||||
|---|---|---|---|---|---|---|---|---|---|
| Speed(RPM) | Current(mA) | Speed(RPM) | Current(mA) | Torque(Kgf.cm) | Current(mA) | Torque(Kgf.cm) | |||
| GM2240 | 1:241 | 4.5 VDC | 52 | ≤ 50 | 40 | ≤ 120 | 1.8 | ≤ 350 | 0.18 |
| 58 | ≤ 65 | 50 | ≤ 130 | 2.4 | ≤ 680 | 2.0 | |||
| 68 | 75 | 56 | ≤ 140 | 2.6 | ≤ 750 | 2.2 | |||
| Model | Voltage (V) | No-Load Speed | No-Load Current | Rated Speed | Rated Torque | Stall Current |
|---|---|---|---|---|---|---|
| SL-N20-04510500 | 4.5V | 10500 RPM | ≤ 30mA | 8250 RPM | 2.0 gf.cm | ≤ 300mA |
| SL-N20-04514000 | 4.5V | 14000 RPM | ≤ 40mA | 12000 RPM | 2.5 gf.cm | ≤ 680mA |
| SL-N20-04516500 | 4.5V | 16500 RPM | ≤ 50mA | 13500 RPM | 2.5 gf.cm | ≤ 750mA |
With over 14 years of experience in motor production, our professional R&D team and mature management ensure a high-quality production environment and superior product performance.
Quality is the foundation of our development. Every step from material reception to final shipment is meticulously checked. We utilize advanced testing equipment including Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, and Life Testers.
