Custom Small DC Motor Brush Low RPM 2.4V 3.7V 5V DC Electric Mini Vibrator Motor
âš¡ Professional Promotion
Technical Specifications
| MODEL |
RATED |
NO LOAD |
RATED LOAD |
STALL |
| VOLTAGE (V) |
SPEED (r/min) |
CURRENT (mA) |
SPEED (r/min) |
CURRENT (mA) |
CURRENT (mA) |
| 0724-V1 |
1.5 |
19900 |
45 |
17600 |
108 |
480 |
| 0724-V2 |
5.0 |
20000 |
33 |
18500 |
65 |
400 |
| 0724-V3 |
3.0 |
25300 |
28 |
21300 |
89 |
370 |
Product Details & Applications
Frequently Asked Questions
What voltage options are available for this micro vibrator motor?
This custom motor series supports various voltage requirements including 1.5V, 2.4V, 3.0V, 3.7V, and 5V DC to suit different power supply designs.
What are the typical applications for the 0724 model motor?
The 0724 micro motor is widely used in adult toys, personal care products, facial massagers, and other small electronic devices requiring vibration functions.
Is the RPM customizable for specific needs?
Yes, the speed (RPM) can be adjusted based on the input voltage and specific customization requests, with typical no-load speeds ranging from 19,900 to 25,300 r/min.
What is the stall current for these motors?
Depending on the model, the stall current ranges from 370mA to 480mA, ensuring high efficiency for micro-scale operations.
Does the motor include vibration weights?
These are micro vibrator motors specifically designed for high-frequency vibration, featuring integrated eccentric weights as shown in the product specifications.
What is the advantage of the brush DC design?
The brush DC design provides a cost-effective, simple-to-control, and reliable solution for small electronic devices requiring compact motion or vibration.
