Spiro Gear
Spiro Gear
| Ratio | Max. Rated Torque | Max. Gear Breaked Torque | Gearbox Efficiency |
| 241k | 1.5~2.0 Kgf.cm | 4~5 Kgf.cm | 45%~60% |
| Model | Ratio | Voltage | No-Load | Rated | Stall | ||||
|---|---|---|---|---|---|---|---|---|---|
| Speed (RPM) | Current (mA) | Speed (RPM) | Current (mA) | Torque (Kgf.cm) | Current (mA) | Torque (Kgf.cm) | |||
| GM2215FMN20-241K | 1:241 | 4.5 VDC | 43 | ≤ 50 | 34 | ≤ 120 | 2.5 | ≤ 350 | 1.5 |
| 58 | ≤ 65 | 50 | ≤ 130 | 2.8 | ≤ 680 | 1.8 | |||
| 68 | 75 | 56 | ≤ 140 | 3.0 | ≤ 750 | 2.0 | |||
| PMDC Model | Voltage | No-Load Speed | No-Load Current | Rated Speed | Rated Torque (gf.cm) | Stall Torque (gf.cm) |
|---|---|---|---|---|---|---|
| SL-N20-04510500 | 4.5VDC | 10500 | ≤ 30mA | 8250 | 2.0 | 10.5 |
| SL-N20-04514000 | 4.5VDC | 14000 | ≤ 40mA | 12000 | 2.5 | 15.0 |
| SL-N20-04516500 | 4.5VDC | 16500 | ≤ 50mA | 13500 | 2.5 | 18.0 |
We are a factory specializing in producing motors for more than 14 years. Our professional R&D team and mature management system ensure a high-quality production process and a reliable experience for all our clients.
To ensure peak performance, every step from material sourcing to final shipment is carefully inspected. Quality is the foundation of our development, and we utilize advanced testing equipment to maintain excellence.
