SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W

Send Inquiry

Product Description

📋 Product Description

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
		Operating Range	Nominal	Speed	Current	Speed	Current	Torque	Power	Current	Torque
		Operating Range	Nominal	RPM	mA	RPM	mA	mN.m / gf.cm	W	mA	mN.m / gf.cm
RF-370CA	061700	6.0~24.0	24 VDC	1320	3	1000	8	0.98/10	0.1	260	4.02/41
RC-370CH	20123	3.0~6.0	6 VDC	8000	70	6878	420	2.4/24.5	1.71	2550	17/173
RC-370SH	4730	3.0~5.0	4.5 VDC	17500	550	15199	3630	7.2/73.4	11.51	24000	55/561
RC-370SH	18139	6.0~12.0	12 VDC	10000	130	8439	700	5.8/59.2	5.17	3800	37.5/382.5

🚀 Application Scenarios

❓ Frequently Asked Questions

What is the nominal voltage for the SRC-370SH-4730?

The nominal voltage is 4.5 VDC, with an operating range typically between 3.0V and 5.0V for optimal performance.

How high is the no-load speed of this motor?

At 4.5V, the no-load speed reaches approximately 17,500 RPM.

What is the rated power output?

The motor delivers a high power output of 11.51W under rated conditions, making it suitable for high-performance micro-applications.

In what applications are these PMDC motors commonly used?

These motors are widely utilized in security systems, children's toys, household appliances, and various small precision electrical devices.

Can this motor handle high stall current?

Yes, the stall current is measured at 24,000 mA (24A) with a stall torque of 55 mN.m. Ensure your power supply can handle peak loads.

Are there different models available in the 370 series?

Yes, the series includes RF-370CA, RC-370CH, and RC-370SH with various voltage ratings ranging from 3.0V up to 24V to meet different speed and torque requirements.
