Spiro Gear
Spiro Gear
▶ RS - 755 H
▶ RS - 775 H
* The length of shaft can be customized.
| Model | Rated Voltage (V) | No-Load | Rated | Stall | ||||||
|---|---|---|---|---|---|---|---|---|---|---|
| Range | Nominal | Speed (RPM) | Current (A) | Speed (RPM) | Current (A) | Torque (mN.m) | Power (W) | Current (A) | Torque (mN.m) | |
| RS-750H | 6.0~12.0 | 12 VDC | 15000 | 1.79 | 12671 | 7.52 | 48.6 | 66.6 | 55.6 | 393.1 |
| RS-755H | 3.0~6.0 | 6 VDC | 9500 | 2.26 | 8123 | 9.31 | 45.1 | 38.2 | 66.34 | 306.9 |
We are a factory specializing in producing motors for more than 14 years. With a professional R&D team, mature management, and experienced engineers, we ensure a high-quality manufacturing process.
To confirm quality, we check every step from material reception to final shipment. Quality is the basis of our development.
